Rental Rigol DSA815-TG 1.5GHz Spectrum Analyser with Tracking Generator

£157.50 (£189.00 inc VAT)

Rental Price Per Week

Only 1 left in stock!

Availability: Stock models delivered next working day (UK only) for orders placed before 15:00 (Mon - Fri)

Free RK Kit Price Match Guarantee

Description


Rigol Rental DSA815-TG Spectrum Analyser

The DSA815-TG has a Minimum Resolution Bandwidth of 10Hz and a Frequency Range of 9kHz to 1.5GHz. The Rigol DSA800 series of spectrum analysers are small, light weight, easy to use and great value for money. The quality, performance and features of these instruments, including the high definition colour LCD display and various remote communication interfaces, make these spectrum analysers highly versatile - Ideal for various environments such as R&D laboratories, education, manufacturing and the home-lab of the electronics enthusiast. A Rigol DSA800 series spectrum analyser, Rigol S1210 EMI pre-compliance test PC software and the TEKBOX range of EMC pre-compliance test equipment (near-field probes, LISNs and TEM cells) form a powerful and affordable system for EMC pre-compliance tests - An effective de-risking strategy, potentially saving a small fortune and project delays due to re-tests at an EMC Test House. Choose a Rigol DSA800 spectrum analyser with built-in tracking generator and you'll have the capability of making (forward and reverse) transmission measurements (e.g. Measuring the frequency response of filters or amplifiers). Add a Rigol VSWR Bridge and you'd have the additional capability of measuring input or output return loss (e.g. Impedance matching and antenna tuning). The Rigol DSA800 series spectrum analysers have several other options available to enhance the capability and user experience even further. Whatever configuration you choose, we think that you'll be impressed by the powerful combination of quality, performance, functionality and value for money. Features:
  • Frequency range from 9kHz to 1.5GHz
  • Built-in tracking generator
  • Displayed average noise level (DANL) <-155dBm/Hz typ. with preamplifier on
  • Minimum resolution bandwidth (RBW) 10Hz
  • Phase noise <-80dBc/Hz @10kHz offset
  • Level measurement uncertainty <1.5dB nom.
  • AM/FM demodulation function
  • 8" (800 x 480) high-definition display
  • Linear and logarithmic frequency axis
  • Connectivity: LAN(LXI), USB Host & Device
  • PictBridge support
  • Compact size and light weight
  • Supplied with... UK & European mains leads, quick guide
  • Optional PC software... Ultra Spectrum, S1210 EMI Pre-Compliance Test
  • Other options include... VSWR bridge (1MHz to 3.2GHz), EMI filter & quasi-peak detector, advanced measurement functions, signal seamless capture, USB to GPIB module, rack mount kit, soft carry bag, RF transmitter demo kit, RF receiver demo kit, RCL standard calibration

Product Videos

RIGOL's DSA800 series Spectrum Analyzers
Rigol DSA815 Spectrum Analyser Teardown
RIGOL DSA800 Series discovers mystery mil-spec cavity filter

Documentation

Frequency
Frequency Range DSA815: 9kHz to 1.5GHz
DSA832: 9kHz to 3.2GHz
DSA875: 9kHz to 7.5GHz
DSA832E: 9kHz to 3.2GHz
Frequency Resolution 1Hz
Internal Reference Frequency
Reference frequency 10MHz
Accuracy ± [(time since last adjustment × aging rate) + temperature stability +
calibration accuracy]
Initial calibration accuracy <1 ppm
Temperature stability 0℃ to 50℃ , reference to 25℃
DSA815: <2 ppm
DSA832: <0.5 ppm
DSA875: <0.5 ppm
DSA832E: <1 ppm
Aging Rate DSA815: <2 ppm/year
DSA832: <1 ppm/year
DSA875: <1 ppm/year
DSA832E: <2 ppm/year
Frequency Readout Accuracy
Marker Resolution span/ (number of sweep points – 1)
Marker Uncertainty ± (frequency indication × frequency reference uncertainty + 1% × span + 10% × resolution
bandwidth + marker resolution)
Frequency Counter
Resolution 1 Hz, 10 Hz, 100 Hz, 1 kHz, 10 kHz, 100 kHz
Uncertainty ± (frequency indication × reference frequency accuracy + counter resolution)
Frequency Span
Range 0 Hz, 100 Hz to maximum frequency of instrument
Uncertainty ±span/ (number of sweep points – 1)
Amplitude
Measurement Range
Range fc ≥ 10 MHz
DANL to +20 dBm
Maximum Input Level
DC Voltage 50V
CW RF Power attenuation = 30 dB
+20 dBm (100 mW)
Max. Damage Level +30dBm (1W)
Level Display
Logarithmic level axis 1 dB to 200 dB
Linear level axis 0 to reference level
Number of display points 601
Number of traces 3 + math trace
Trace detectors normal, positive-peak, negative-peak, sample, RMS, voltage average
quasi-peak (with EMI-DSA800 option)
Trace functions clear write, max hold, min hold, average, view, blank
Units of level axis dBm,dBmV, dBμV, nV, μV, mV, V, nW, μW, mW, W
Input / Output
Front Panel Connectors
RF Input impedance 50 Ω (nom.)
connector N female
Tracking Generator Output impedance 50 Ω (nom.)
connector N female
Internal / External Reference
Internal Reference Frequency 10 MHz
Output level +3 dBm to +10 dBm, +8 dBm (typ.)
Impedance 50 Ω (nom.)
Connector BNC female
External Reference Frequency 10 MHz ±5 ppm
Input level 0 dBm to +10 dBm
Impedance 50 Ω (nom.)
Connector BNC female
External Trigger Input
External Trigger Input Impedance 1 kΩ (nom.)
Connector BNC female
Communication Interface
USB Host Connector: A plug
Protocol: version2.0
USB Device Connector: B plug
Protocol: version2.0
LAN LXI core 2011 device: 10/100Base, RJ-45
General Specifications
Display
Type TFT LCD
Resolution 800 x 480 pixels
Size 8 inch
Colours 64 k
Power Supply
Input voltage range, AC 100 V to 240 V (nom.)
AC supply frequency 45 Hz to 440 Hz
Power consumption 35 W (typ.), max. 50 W with all options
Environmental
Temperature Operating
temperature range: 0℃ to 50℃
Storage
temperature range: -20℃ to 70℃
Humidity 0℃ to 30℃ ≤95% rel. humidity
30℃ to 40℃ ≤75% rel. humidity
Altitude Operating height up to 3,000m

Note*

Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
