Kikusui PLZ-5WZ Series Multifunctional DC Electronic Loads

Input Voltage: 0.25 – 150V | Input Current: 0 – 240A | Power: 1200W, 400W, 200W

The all-new PLZ-5WZ series allows for easily configured impedance measurements with dedicated impedance measurement software.
Impedance measurements are made during discharge, allowing for real-time measurement of impedance values from the DUT.
Capable of R, jX, θ, and Z measurements.
Measures AC frequency from 100 Hz – 10 kHz (seven fixed settings) and signal levels can be set arbitrarily.
Equipped with a voltage slope correction function that minimizes the effect of voltage slope during during battery discharge tests.
Zero adjustment function allows for increased accuracy during critical impedance measurements.
Measurement results and graphical information can be copied directly from the application software to programs like Excel.

SKU	Input Voltage / Current / Power	Modes	CC Dynamic Mode Frequency	Current Slew Rate	Readback Current Resolution	Ports	Stock Status	Price
PLZ1205WZLow stock	150 V / 240 A / 1.2 kW	CC / CR / CV / CP / CC+CV / CR+CV	100 kHz	0.0006–60 A/µs*	0.05 mA*	LAN / USB / RS-232 / GPIB (Optional)	1	£4,938.00
PLZ205WZ	150 V / 40 A / 200 W	CC / CR / CV / CP / CC+CV / CR+CV	100 kHz	0.0001–10 A/µs*	0.01 mA*	LAN / USB / RS-232 / GPIB (Optional)	On Backorder	£2,821.00
PLZ405WZ	150 V / 80 A / 400 W	CC / CR / CV / CP / CC+CV / CR+CV	100 kHz	0.0002–20 A/µs*	0.02 mA*	LAN / USB / RS-232 / GPIB (Optional)	On Backorder	£3,243.00

Showing all 4 results

Kikusui PLZ1205WZ Multifunctional DC Electronic Load
