Siglent F503ME Mechanical Calibration Kit, Type-N Male, DC to 4.5 GHz

Name: Siglent F503ME Mechanical Calibration Kit, Type-N Male, DC to 4.5 GHz
Brand: Siglent
SKU: F503ME
Price: 285.00 GBP
Availability: BackOrder

£285.00 (£342.00 inc. VAT)

Available on back-order

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

Facebook

Post

SKU: F503ME Categories: Calibration & Accuracy, Hardware, Optional Accessories Brand: Siglent

Compare with other Calibration & Accuracy

SKU	Brand	Frequency Range	Connectors	Impendance	Includes	Stock	Price
F503ME	Siglent	DC to 4.5 GHz	Type-N Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£285.00
CK106A	Rigol	DC to 6.5 GHz	Type-N Male standards; Type-N Female-to-Female thru	50 Ω	Type-N Male load, open and short; Type-N Female-to-Female thru adaptor	On Backorder	£785.00
CK106E	Rigol	DC to 1.5 GHz	Type-N Male standards; Type-N Female-to-Female thru	50 Ω	Type-N Male load, open and short; Type-N Female-to-Female thru adaptor	On Backorder	£275.00
ECAL109-NF2	Rigol	100 kHz to 9 GHz	Type-N Female	50 Ω	USB 2.0 cable	On Backorder	£2,962.00
ECAL109-NF4New	Rigol	100 kHz to 9 GHz	Type-N Female	50 Ω	USB 2.0 cable	On Backorder	£4,451.00
ECAL114-NF2	Rigol	100 kHz to 14 GHz	Type-N Female	50 Ω	USB 2.0 cable	On Backorder	£3,333.00
ECAL114-NF4New	Rigol	100 kHz to 14 GHz	Type-N Female	50 Ω	USB 2.0 cable	On Backorder	£4,880.00
ECAL126-35F2	Rigol	100 kHz to 26.5 GHz	3.5 mm Female	50 Ω	USB 2.0 cable	On Backorder	£4,444.00
ECAL126-35F4New	Rigol	100 kHz to 26.5 GHz	3.5 mm Female	50 Ω	USB 2.0 cable	On Backorder	£6,595.00
ECAL209-NF4New	Rigol	DC to 9 GHz	Type-N Female	50 Ω	USB 2.0 cable	On Backorder	£4,880.00
ECAL214-NF4New	Rigol	DC to 14 GHz	Type-N Female	50 Ω	USB 2.0 cable	On Backorder	£5,480.00
ECAL226-35F4New	Rigol	DC to 26.5 GHz	3.5 mm Female	50 Ω	USB 2.0 cable	On Backorder	£7,281.00
ECAL304-NF2Low stock	Rigol	100 kHz to 4.5 GHz	Type-N Female	50 Ω	USB 2.0 cable	2	£815.00
ECAL304-SF2Low stock	Rigol	100 kHz to 4.5 GHz	SMA Female	50 Ω	USB 2.0 cable	1	£815.00
ECAL309-NF2Low stock	Rigol	100 kHz to 9 GHz	Type-N Female	50 Ω	USB 2.0 cable	1	£1,333.00
ECAL309-SF2Low stock	Rigol	100 kHz to 9 GHz	SMA Female	50 Ω	USB 2.0 cable	1	£1,333.00
ECAL314-NF2Low stock	Rigol	100 kHz to 14 GHz	Type-N Female	50 Ω	USB 2.0 cable	1	£2,222.00
ECAL314-SF2Low stock	Rigol	100 kHz to 14 GHz	SMA Female	50 Ω	USB 2.0 cable	1	£2,222.00
MCAL104-NF1Low stock	Rigol	DC to 4.5 GHz	Type-N Female	50 Ω	Open, short, load and Type-N Female-to-Female adapter	1	£347.00
MCAL104-NM1	Rigol	DC to 4.5 GHz	Type-N Male	50 Ω	Open, short, load and Type-N Male-to-Male adapter	On Backorder	£347.00
MCAL104-SF1	Rigol	DC to 4.5 GHz	3.5 mm Female	50 Ω	Open, short, load and 3.5 mm Female-to-Female adapter	On Backorder	£428.00
MCAL104-SM1Low stock	Rigol	DC to 4.5 GHz	3.5 mm Male	50 Ω	Open, short, load and 3.5 mm Male-to-Male adapter	1	£434.00
MCAL109-NF1Low stock	Rigol	DC to 9 GHz	Type-N Female	50 Ω	Open, short, load and Type-N Female-to-Female adapter	1	£1,130.00
MCAL109-NK1	Rigol	DC to 9 GHz	Type-N Male and Female	50 Ω	Male and female open, short and load standards; three Type-N adapters; torque wrench; tool kit	On Backorder	£2,173.00
MCAL109-NM1	Rigol	DC to 9 GHz	Type-N Male	50 Ω	Open, short, load and Type-N Male-to-Male adapter	On Backorder	£1,114.00
MCAL109-SF1	Rigol	DC to 9 GHz	3.5 mm Female	50 Ω	Open, short, load and 3.5 mm Female-to-Female adapter	On Backorder	£1,371.00
MCAL109-SK1	Rigol	DC to 9 GHz	3.5 mm Male and Female	50 Ω	Male and female open, short and load standards; three 3.5 mm adapters; connector bodies; torque wrench; hex wrenches; tool kit	On Backorder	£2,370.00
MCAL109-SM1	Rigol	DC to 9 GHz	3.5 mm Male	50 Ω	Open, short, load and 3.5 mm Male-to-Male adapter	On Backorder	£1,390.00
MCAL126-35K1	Rigol	DC to 26.5 GHz	3.5 mm Male and Female	50 Ω	Male and female open, short and load standards; three 3.5 mm adapters; torque wrench; tool kit	On Backorder	£3,555.00
MCAL226-35F5	Rigol	DC to 26.5 GHz	3.5 mm Female	50 Ω	Integrated 4-in-1 open, short, load and thru standards	On Backorder	£2,782.00
F503FE	Siglent	DC to 4.5 GHz	Type-N Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£285.00
F504FS	Siglent	DC to 9 GHz	Type-N Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,069.00
F504MS	Siglent	DC to 9 GHz	Type-N Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,069.00
F504TS	Siglent	DC to 9 GHz	Type-N Male and Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,398.00
F505FSNew	Siglent	DC to 18 GHz	Type-N Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,983.00
F505MSNew	Siglent	DC to 18 GHz	Type-N Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,983.00
F505TS	Siglent	DC to 18 GHz	Type-N Male and Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£3,466.00
F603FE	Siglent	DC to 4.5 GHz	3.5 mm Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£353.00
F603ME	Siglent	DC to 4.5 GHz	3.5 mm Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£353.00
F604FS	Siglent	DC to 9 GHz	3.5 mm Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,263.00
F604MS	Siglent	DC to 9 GHz	3.5 mm Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,263.00
F604TS	Siglent	DC to 9 GHz	3.5 mm Male and Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£2,131.00
F606FSNew	Siglent	DC to 26.5 GHz	3.5 mm Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,722.00
F606MSNew	Siglent	DC to 26.5 GHz	3.5 mm Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£2,070.00
F606TS	Siglent	DC to 26.5 GHz	3.5 mm Male and Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£3,627.00
KWR42ALow stock	Siglent	17.6 GHz to 26.7 GHz	K-band WR42 waveguide	50 Ω	Through, reflect and line calibration standards	1	£4,267.00
SEM5002ANew	Siglent	9 kHz to 4.5 GHz	SMA Female	50 Ω	1 × quick-start guide and 1 × USB 2.0 cable	On Backorder	£1,804.00
SEM5004A	Siglent	9 kHz to 4.5 GHz	SMA Female	50 Ω	1 × quick-start guide and 1 × USB 2.0 cable	On Backorder	£2,119.00
SEM5012ALow stock	Siglent	9 kHz to 9 GHz	SMA Female	50 Ω	1 × quick-start guide and 1 × USB 2.0 cable	1	£2,280.00
SEM5014A	Siglent	9 kHz to 9 GHz	SMA Female	50 Ω	1 × quick-start guide and 1 × USB 2.0 cable	On Backorder	£3,695.00
SEM5022A	Siglent	100 kHz to 13.5 GHz	3.5 mm Female	50 Ω	1 × quick-start guide and 1 × USB 2.0 cable	On Backorder	£2,576.00
SEM5024A	Siglent	100 kHz to 13.5 GHz	3.5 mm Female	50 Ω	1 × quick-start guide and 1 × USB 2.0 cable	On Backorder	£5,271.00
SEM5032A	Siglent	100 kHz to 26.5 GHz	3.5 mm Female	50 Ω	1 × quick-start guide and 1 × USB 2.0 cable	On Backorder	£3,364.00
SEM5034A	Siglent	100 kHz to 26.5 GHz	3.5 mm Female	50 Ω	1 × quick-start guide and 1 × USB 2.0 cable	On Backorder	£8,424.00
Y504FS	Siglent	DC to 9 GHz	Type-N Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,626.00
Y504MS	Siglent	DC to 9 GHz	Type-N Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£1,626.00
Y606FSNew	Siglent	DC to 26.5 GHz	3.5 mm Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£2,417.00
Y606MSNew	Siglent	DC to 26.5 GHz	3.5 mm Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£2,417.00
TBVC-NF6	Tekbox	DC to 6 GHz	N-Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£300.00
TBVC-NM6	Tekbox	DC to 6 GHz	N-Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£300.00
TBVC-SF6	Tekbox	DC to 6 GHz	3.5 mm / SMA Female	50 Ω	Open, short, load and through calibration standards	On Backorder	£396.00
TBVC-SM6	Tekbox	DC to 6 GHz	3.5 mm / SMA Male	50 Ω	Open, short, load and through calibration standards	On Backorder	£396.00

Description

Siglent F503ME Mechanical Calibration Kit, Type-N Male, DC to 4.5 GHz

The F503ME is a separate OSLT mechanical calibration kit for characterising systematic errors when calibrating scalar or vector network analysers. It covers DC to 4.5 GHz and uses Type-N Male calibration standards.

Key Features

DC to 4.5 GHz frequency range
Type-N Male interface
50 Ω nominal impedance
OSLT calibration standards
Separate construction
Open, short, load and through calibration standards

Applications

Calibration of vector network analysers
Calibration of scalar network analysers
Coaxial RF measurement-system error correction

Documentation

Mechanical Calibration Kit Datasheet EN03C

SEM5000A Datasheet

Brand	Siglent
Model	F503ME
Product type	Mechanical calibration kit
Calibration method	OSLT
Frequency range	DC to 4.5 GHz
Connector / interface	Type-N Male
Impedance	50 Ω
Construction	Separate
Kit contents	Open, short, load and through calibration standards
