TEKBOX TBL5016-2 50uH 16A Line Impedance Stabilisation Network LISN, CISPR 16-1-2

Description

Tekbox TBL5016-2 LISN

The Tekbox TBL5016-2 is a Line Impedance Stabilisation Network for the measurement of line-conducted interference within the range of 9kHz to 30MHz, according to the CISPR 16-1-2 standard.

The device is designed for testing single phase, AC-powered equipment with supply voltages up to maximum 240V and 16A.

Conducted noise can be measured on the phase and on the neutral conductor. The TBL5016-2 is equipped with a switchable limiter/attenuator and an artificial hand connection.

The device is available with country-specific DUT connectors.

Features:

• Frequency range: 9 kHz to 30 MHz
• Impedance: 50 Ω ║ (50 µH + 5 Ω)
• Artificial hand: 220 pF + 511 Ω
• Switchable PE: 50 Ω ║ 50 µH
• Limiter / attenuator: 150 kHz to 30 MHz; 10 dB
• Air core inductors
• Line voltage: max. 240V / 50 – 60 Hz, CAT ‖‖
• Max. current: 16A @ 23°C
• DUT socket: country specific
• Measurement connector: 50 Ω BNC
• Power connector: IEC 60320 C19
• Operating Temperature Range: +5°C … + 40°C; 5% to 80% RH
• Safety: Safety Class I, IEC 1010-01
