Kikusui PWR2001L (0-40V 0-200A 2000W) Programmable Bench DC Power Supply

£3043.00 (£3,651.60 inc VAT)

1 in stock (can be backordered)

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

Request QuoteRemove from Quote
Request Quote
SKU: PWR2001L Category:

Description


Kikusui PWR2001L DC Power Supply

The PWR2001L (0-40V 0-200A 2000W) is part of the Kikusui PWR-01 series of high performance, compact, wide-range Programmable Bench DC power supplies. The series consists of 13 models in total with 4 maximum voltage outputs (L, ML, MH, and H) and 4 maximum power outputs (400W, 800W, 1200W and 2000W). With the PWR-01 series you can set sequences with an embedded CPU as well as analogue control. The series is equipped with LAN (LXI), USB, and RS232C as standard interfaces that are essential for system integration. The PWR-01 also features front-facing output terminals in addition to the rear terminals, variable internal resistance, bleeder ON/OFF functions, CC/CV priority switching function, synchronised operation, various protection functions and programmable internal memory.

Features:

  • Sequence function (supports triggered synchronisation)
  • Variable internal resistance function
  • LAN (LXI compliant) /USB/RS232X as standard interface
  • A virtual multi-channel bus (VMCB) function makes multi-channel operation more efficient
  • A wide range of voltage and current settings can be combined within its output power rating (3 to 4 times)
  • All models are equipped with front-facing output terminals as standard (maximum 10A)
  • Supporting universal input voltage (85V to 265V)
  • CONFIG setting shortcut function and display (up to three parameters can be registered)
  • Setting preset memory function (3 combinations of settings for voltage, current, OVP, OCP, abd UVL)
  • Bleeder (sink) can be turned on/off, with an even stronger bleeder more setting available
  • Output-on/off delay function
  • Soft start/stop function

Product Images

Product Videos

YouTube Video
PWR 01 Basic operation
YouTube Video
Kikusui PWR 01 DC Programmable DC Power Supply Overview
YouTube Video
PWR 01 Protections
YouTube Video
PWR 01 Config Commands
YouTube Video
PWR 01 Basic USB Connection
YouTube Video
PWR 01 Basic LAN Connection

Documentation

Datasheet

Kikusui PWR-01 Datasheet



User Manual

Kikusui PWR-01 User Manual



Application Notes

A single PWR-01 can cover an extensive output range equivalent to what is provided by three to six conventional single range DC power supplies

Various features to advance your test

Power supply with high precision

Parallel Operation with Different Power Supply Models

How to Enable Positive/Negative Output from DC Power Supply

Blown Fuse Testing Precautions When Using Electronic Load

Output Connection Methods with Parallel Control

What It Takes to Keep Regulated DC Power Supply Stable Part 1: Connecting Cable

How to Select a Right DC Power Supply Part 2: Key Considerations

What It Takes to Keep Regulated DC Power Supply Stable Part 2: Load Conditions

What Makes a Good Power Supply?

DC Power Supply Sinks Current when Output is Turned Off

How to Balance Battery Module Charge-Discharge



AC Input
ModelPWR2001LPWR2001ML
Nominal input rating100 Vac to 240 Vac, 50 Hz to 60 Hz, single phase100 Vac to 240 Vac, 50 Hz to 60 Hz, single phase
Input voltage range85 Vac to 265 Vac85 Vac to 265 Vac
Input frequency range47 Hz to 63 Hz47 Hz to 63 Hz
Current (TYP)
100 Vac28.0A28.0A
200 Vac14.0A14.0A
Inrush current (MAX)125A peak or less125A peak or less
Power (MAX)2800VA2800VA
Power factor (TYP)0.99 (input voltage: 100 V), 0.97 (input voltage: 200 V)0.99 (input voltage: 100 V), 0.97 (input voltage: 200 V)
Efficiency (MIN)75 % (TYP)75 % (TYP)
Hold-up time for power interruption (MIN)20 ms or more20 ms or more
Output
Rating
Output voltage40V80V
Output Current200A100A
Output power2000W2000W
Voltage
Maximum settable voltage42V84V
Setting accuracy± (0.05 % of set +0.05 % of rating)± (0.05 % of set +0.05 % of rating)
Resolution200mV400mV
Using FINE, OUT OFF10mV10mV
Using FINE, OUT ON1mV1mV
When using a communication interface1mV1mV
Line regulation±6 mV±10 mV
Load regulation±6 mV±10 mV
Transient response1 ms or less2 ms or less
Ripple noise
p-p50mV70mV
rms5mV5mV
Rise Time
At full load50 ms or less50 ms or less
No load50 ms or less50 ms or less
Fall Time
At full load50 ms or less50 ms or less
No load500 ms or less500 ms or less
Maximum remote sensing compensation voltage (single line)1.5V4V
Temperature coefficient100 ppm/°C100 ppm/°C
Current
Maximum settable current210A105A
Setting accuracy± (0.5 % of set +0.1 % of rating)± (0.5 % of set +0.1 % of rating)
Resolution1000mA500mA
Using FINE, OUT OFF100mA100mA
Using FINE, OUT ON10mA10mA
When using a communication interface10mA10mA
Line regulation±22 mA±12 mA
Load regulation±45 mA±25 mA
Ripple noise rms400mA200mA
Rise time (TYP) At full load50ms50ms
Fall time (TYP) At full load50ms50ms
Temperature coefficient100 ppm/°C100 ppm/°C
Maximum internal resistance that can be set0.200 Ω0.800 Ω

Note* Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
