Siglent SSA5000A Series Spectrum Analyser

Frequency Range: 9 kHz to 13.6/26.5GHz Models| Resolution Bandwidth(RBW): 1Hz to 10MHz | Total Amplitude Accuracy: < 0.5 dB

Spectrum Analyzer Frequency Range from 9 kHz up to 13.6 GHz/26.5 GHz
-165 dBm/Hz Displayed Average Noise Level (Typ.)
-105 dBc/Hz@1 GHz,10 kHz offset SSB Phase Noise (Typ.)
25 MHz/40 MHz Real Time Analysis Bandwidth (opt)
100% POI 7.20 μs, Dynamic Range 60 dB, Multi-view for Density, Spectrogram and PvT
Channel power, ACPR, OBW, Harmonic, TOI measurement etc. (opt)
Analogue Modulation Analysis and Vector Digital Modulation Analysis (opt)
12.1 inch Multi-Touch Screen, HDMI output
Web Browser Remote Control on PC and Mobile Terminals and File Operation

The SIGLENT SSA5000A spectrum analysers are powerful and flexible tools for complex RF spectrum and signal analysis. With the capability of real-time spectrum analysis, the analyser can provide multi-dimensions data displays, and advanced triggering to solve modern RF spectrum challenges, like channel power measurement, hopping frequency, conflict channel, and spectrum interference.

Applications include broadcast monitoring/evaluation, cellular site, IoT, WLAN and Bluetooth surveying, research and development, education, production, and maintenance

SKU	Image	Frequency	RBW	Phase Noises	DANL	Pre-Amplifier	Tracking Gen	Stock	Price
SSA5083A		9 kHz–13.6 GHz	v1 Hz–10 MHz	−105 dBc/Hz typ.	−165 dBm/Hz typ.	Standard	N/A	On Backorder	£13,467.00
SSA5085A		9 kHz–26.5 GHz	1 Hz–10 MHz	−105 dBc/Hz typ.	−165 dBm/Hz typ.	Standard	N/A	On Backorder	£15,777.00

Showing all 2 results

Siglent SSA5083A 13.6GHz Spectrum Analyser
