Siglent SSG6000A RF Signal Generator

Frequency Range: 13.6 GHz ,20 GHz Models & 40GHz Models | Excellent Phase Noise: Phase Noise: -135 dBc / Hz @ 1 GHz,20 kHz offset (typ.) | AM Modulation, Step Attenuator, OCXO all standard.

  • Frequency up to 13.6 GHz / 20 GHz / 40GHz
  • Level setting range: -130 dBm ~ 24 dBm
  • Excellent Phase Noise: -135 dBc / Hz @ 1 GHz,20 kHz offset (typ.)
  • Very Low Sub harmonic: <80dBc
  • Level error ≤ 0.7 dB (typ.)
  • Standard AM modulation with internal, external or Int+Ext source
  • Standard OCXO and step attenuator (0 to 110 dB, 10dB step)
  • Pulse modulation on/off ration > 80 dBc (typ.) and the rise/fall time < 15 ns (typ.) (option)
  • Pulse train generator has pulse width of 20 ns ~ 300 s and as many as 2047 different pulses (option)
  • Web browser remote control on PC and mobile terminals
  • 5 inch TFT capacitive touch screen, mouse and keyboard supported
  • Standard interface includes USB Host, USB Device (USB TMC), LAN (VXI-11, Socket, Telnet). Optional interface: GPIB

Siglent’s SSG6000A Series RF Signal Generator supports AM and pulse modulation, pulse sequence generator, power meter control and other functions. With standard OCXO reference hardware module inside ensures high-precision and high stability signal output. It is not only an ideal local oscillator and clock source, but also a high-performance analogue signal source suitable for applications in R&D and production. SIGLENT provides a total solution backed by proven reliability and our standard 3 years warranty plus pre-sale and post-sale support. Coupled with solid RF performance, a flexible and pure signal, the SSG6000A is a complete solution that makes a great addition to any RF engineer’s workbench kit.
