Danisense DL2000UB-10V Zero Flux Current Transducer AC:1414Arms, DC:2000A

£4056.00 (£4867.20 inc. VAT)

Available on back-order

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

SKU: DL2000UB-10V Categories: , Tags: , , Brand:

Compare with other 600A to 3000A Current Transducers

SKUImageOutput TypeOptionsRangeACDCRatioAccuracyBandwidthAperture DiameterStockPrice
DL2000UB-10VImage of Danisense dl2000ub 1vVoltageStandard2200 A1414 A2000 A5 mV/A108 ppm300 kHz150.0 mmOn Backorder£4,056.00
DL2000IDImage of Dl2000idCurrentStandard3000 A2000 A3000 A1:15007 ppm300 kHz68.0 mmOn Backorder£3,605.00
DL2000ID-CB100Image of Danisense 5CurrentCalibration Winding1500 A1000 A1000 A1:50007 ppm400 kHz41.2 mmOn Backorder£3,831.00
DL2000ID-CD100Image of Dl2000idCurrentCalibration Winding3000 A2000 A3000 A1:15007 ppm300 kHz68.0 mmOn Backorder£3,831.00
DL2000UB-1VImage of Danisense dl2000ub 1vVoltageStandard3000 A2000 A3000 A0.5 mV/A106 ppm300 kHz68.0 mmOn Backorder£3,943.00
DM1200IDImage of Dm1200idCurrentStandard1800 A 1200 A1500 A1:15006 ppm400 kHz45.0 mmOn Backorder£1,505.00
DM1200ID-CD3000Image of Dm1200idCurrentCalibration Winding1800 A 1200 A1500 A1:15006 ppm400 kHz45.0 mmOn Backorder£1,719.00
DM1200UB-10VImage of Danisense dm1200ub 1v telonicukVoltageStandard1320 A850 A1200 A8.33 mVIA75 ppm300 kHz27.6 mmOn Backorder£1,828.00
DS1000UB-10VImage of Danisense ds voltage telonicukVoltageStandard1100 A700 A1000 A10 mV/A45 ppm300 kHz27.6 mmOn Backorder£1,239.00

Description


Danisense DL2000UB-10V Zero Flux Current Transducer

High precision DC current transducer (DCCT) measuring up to 2200 A currents and continuously measuring 2000 A currents with a linearity error less
than 30 ppm. Based on the ultra stable Danisense closed loop flux gate technology, the DL2000UB-10V has very low offset and ultra low drift. With an integrated voltage output module (VOM)
outputting 10V at 2000 A, the DL2000UB-10V makes high current measuring easy. It provides high resolution for precise monitoring, reliable and consistent performance, and a rugged, full aluminium design for durability.

Features
  • 1414 A rms nominal current
  • 10 V output at 2000 A with BNC connector
  • Ø68 mm aperture
  • 108 ppm total accuracy
  • 8 ppm offset
  • Status signal and LED
Applications
  • Space constrained applications
  • Power measurement and power analysis
  • Particles accelerators
  • MRI devices and medical scanners
  • Battery testing and evaluation systems
  • Current calibration purposes
  • Precision current sensing

Documentation

Datasheets: Current transducer 600A to 3000A

Specifications Highlights Symbol Unit Min Typ Max
Nominal primary AC current IPN AC Arms 1414
Nominal primary DC current IP N DC A -2000 2000
Measuring range ÎP M A -2200 2200
Primary / secondary ratio V/kA 5.0000 5.0000
Linearity error ƐL ppm -20 20
Offset current (including earth field) IOE ppm -15 15
DC-10Hz Overall accuracy @23°C (= ?L + IOE ) accƐ ppm -35 35
AC Maximum gain error 10Hz to 1kHz ƐG % ±0.01
Operating temperature range Ta °C -40 65
Power supply voltages Uc V ±14.25 ±15.75

Note* Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
