Rigol DS8204-R 4CH, 2GHz, 10GSa/s Compact Oscilloscope

Description

Rigol DS8204-R Compact Oscilloscope

The DS8204-R 4CH, 2GHz, 10GSa/s is a medium and high-end digital oscilloscope with a compact size designed on the basis of the ASIC chip (RIGOL self-owns its intellectual property right) and UltraVision II technical platform developed by RIGOL. It is compact and thin in design. It supports system integration of multiple devices, rack mount installation, and remote system operation to meet the system requirements for industrial automation test system. DS8000-R series oscilloscope has an analogue bandwidth of up to 2 GHz, supporting multi-device synchronous triggering, available to be extended to 512 channels. It provides an excellent solution for users to meet their middle and high-speed requirement for the system integration test and synchronization requirement for multi-channel data acquisition.

Features:

• Analogue channel bandwidth: 2GHz
• Up to 10GSa/s, 4 analogue channels, 1 EXT input channel
• Standard memory depth up to 500Mpts
• High waveform capture rate (over 600,000wfm/s)
• Low jitter, multiple-device synchronization (<200psRMS, typical)
• Integrates 6 independent instruments into 1, including digital oscilloscope, spectrum analyser, AWG (option), digital voltmeter, 6-digit counter and totalizer, and protocol analyser (option)
• Available to be extended to 512 channels, supporting synchronous acquisition (with the multi-channel synchronization module) Real-time eye diagram and jitter analysis software (option for DS8104-R/DS8204-R, but unavailable for DS8034-R)
• Built-in advanced power analysis software (option)
• Operating temperature low below -40℃, available to be used for signal monitoring in some special conditions Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, 10 MHz In, and 10 MHz Out
• Web Control remote command
• Compact and thin design, save rack space, 1U rack mount kit (standard)
• Software development kit available for users to meet their customised development according to their specific scenarios
• Easy-to-use on-site multi-channel synchronisation calibration kit, enabling you to view multiple channels synchronously

Product Images

Trigger, decode, and visualise serial bus traffic to speed analysis and debug of Embedded Serial Bus designs Learn more...

Minimise scope “dead time” between trigger events and increases observations of random and sporadic events. Learn more...

Full Memory Hardware Measurement Learn more...

Find elusive problems in complex digital streams with long acquisitions at high sample rates Learn more...

Economical and Practical Eye Diagram Pretest Learn more...

2 GHz Performance for Advanced and Serial Analysis Applications Learn more...
