Microtest 6630-5 Precision High Frequency LCR Meter 10Hz to 5MHz

£5038.00 (£6,045.60 inc VAT)

SKU: Microtest6630-5 Categories: ,

Description


Microtest 6630-5 LCR Meter

The 6630-5 precision LCR meter (10 Hz to 5MHz), it is suitable for the LCR testes of AC signals. The measurement in a continuously changing environment can be executed stage-by-stage with the test frequency and grade, and high-speed continuous tests can be performed under different test and mode conditions. The 6630-5 has output impedance 25Ω/100Ω can be switched, Auto Level control(ALC) , List mode function. Comparator function and Handler BIN classification function for component good and defective product classification. It supports RS-232, GPIB, Handler, LAN, USB Host/Device.

The 6630-5 also supports a variety of fixtures, such as liquid dielectric material test fixture, dielectric material test fixture and magnetic material test fixture

Features:

  • Signal Source Frequency Range: 10Hz – 5MHz
  • Basic accuracy up to ±0.05%
  • ALC function
  • Output impedance 25Ω/100Ω, switchable
  • Support meter mode and list mode, can used with various fixtures, such as: liquid dielectric material test fixture, dielectric material test fixture and magnetic material test fixture
  • Ultra-high measuring speed < 3ms
  • Open circuit/short circuit/load calibration function
  • Up to four component parameters can be selected in the electric meter mode. The induction and DCR values can be measured and displayed simultaneously
  • Auto component classification: Comparator function and Handler BIN classification function
  • Support RS-232, GPIB, Handler, LAN, USB Host/Device interfaces
  • PC connection data analysis software is available

Microtest 6630 LCR Meter Comparison Table

MODELTest FrequencyBasic AccuracyDC Drive LevelTest Time (The Fastest)Output ImpedanceMeasurement Circuit
6630-110Hz – 1MHz± 0.05%1V (fixed)< 3ms25Ω/100Ω, switchable (Nominal value)Series/Parallel
6630-310Hz – 3MHz± 0.05%1V (fixed)< 3ms25Ω/100Ω, switchable (Nominal value)Series/Parallel
6630-510Hz – 5MHz± 0.05%1V (fixed)< 3ms25Ω/100Ω, switchable (Nominal value)Series/Parallel
6630-1010Hz – 10MHz± 0.05%1V (fixed)< 3ms25Ω/100Ω, switchable (Nominal value)Series/Parallel
6630-2010Hz – 20MHz± 0.05%1V (fixed)< 3ms25Ω/100Ω, switchable (Nominal value)Series/Parallel
6630-3010Hz – 30MHz± 0.05%1V (fixed)< 3ms25Ω/100Ω, switchable (Nominal value)Series/Parallel
6630-5010Hz – 50MHz± 0.05%1V (fixed)< 3ms25Ω/100Ω, switchable (Nominal value)Series/Parallel

Product Images

Product Videos

YouTube Video
MICROTEST 6630 LCR Tester｜MLCC Measurement｜Impedance Measurement

Documentation

Datasheet

Microtest 6630 Datasheet


Specification
Test Frequency6630 – 1: 10Hz-1MHz
6630-3: 10Hz-3MHz
6630-5: 10Hz-5MHz
6630-10: 10Hz-10MHz
6630-20: 10Hz-20MHz
6630-30: 10Hz-30MHz
Basic Accuracy± 0.05%
AC Drive LevelTest Signal Voltage Level: 10mV – 2Vrms(Ro 100Ω), 10mV – 1Vrms(Ro 25Ω)
Voltage Minimum Resolution: 1mV
Accuracy: ALC ON 6％ * Voltage ± 2mV, ALC OFF：10％ * Voltage ± 2mV
Test Signal Current Level: 200µA – 20mArms
Current Minimum Resolution: 10µA
Accuracy: ALC ON：6％ * Current ± 20µA, ALC OFF：10％ * Current ± 20µA
DC Drive Level1V (fixed)
Test Time (The fastest)< 3ms
Output Impedance25Ω/100Ω, switchable (Nominal value)
Parameters|Z|、|Y|、θ、X、R、G、B、L、D、Q、DCR、C、 Vdc-Idc、ESR、ε’ ε”and μr’ μr”
Measurement ModeMeter mode, list mode
Measurement CircuitSeries/Parallel
CorrectionOpen Circuit/ Short Circuit/Load correction
List Mode50 groups of Multi-steps setting (Each group contains up to 15 steps)
BIN9
ComparatorABS、ΔABS、Δ%、OFF
Built-In Storage100 sets LCR Meter setting documents, 50 sets list mode setting documents
USB Host StorageLCR setting documents, list mode setting documents, BMP graphics
InterfaceRS-232、GPIB、Handler、LAN、USB Host/Device
Power SupplyVoltage: 90V ～ 264Vac
Frequency: 47Hz ~ 63Hz
Power ConsumptionLow power consumption: Maximum 30W (Nominal value)
Display7.0”TFT, 800×480 colour screen
EnvironmentTemperature: 10℃ ～ 40℃ Humidity: ≦80%
Dimension (W*H*D)336x147x340mm
Weight3kg
Parameters Measurement Ranges
|Z|0.000 mΩ – 9999.99 MΩ
R, X± 0.000 mΩ – 9999.99 MΩ
|Y|0.00000 uS – 999.999 kS
G, B± 0.00000 uS – 999.999 kS
θRAD± 0.00000 – 3.14159
θDEG± 0.000° – 180.000°
Cs, Cp± 0.00000 pF – 9999.99 F
Ls, Lp± 0.00 nH – 9999.99 kH
D0.00000 – 9999.99
Q0.00 – 9999.99
Δ± 0.00% – 9999.99%
Rdc0.00 mΩ – 99.9999 MΩ
εr’ εr”0 – 100000
μr’ μr'”0 – 100000
Applications
Passive ComponentsCapacitor, Inductor, Resistor, Transformer, Ceramic resonator, Quartz Crystal
Semiconductor ComponentsThe CV characteristics analysis of varactor diodes, Diodes
Dielectric MaterialEstimation on permittivity and consumption tangent of plastic, ceramic and PCB
Other ComponentsEstimation of the impedance of PCB components

Note*

Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
