Rigol DS9204 4 Channel, 2.5 GHz, 20 GSa/s Digital Oscilloscope

Name: Rigol DS9204 4 Channel, 2.5 GHz, 20 GSa/s Digital Oscilloscope
Brand: Rigol
SKU: DS9204
Availability: BackOrder

£8347.00 (£10016.40 inc. VAT)

Available on back-order

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

SKU: DS9204 Categories: Rigol MSO/DS9000 Series Digital Oscilloscopes, Test & Measurement Brand: Rigol

Description

Rigol DS9204 4 Channel, 2.5 GHz, 20 GSa/s Digital Oscilloscope

The MSO/DS9000 series digital oscilloscope is engineered to meet the demanding requirements of mainstream applications in electronic design, debugging, and advanced testing environments. Powered by RIGOL’s next-generation, self-developed processing module, this versatile instrument delivers unprecedented performance by achieving a blazing-fast waveform capture rate of up to 1,000,000 waveforms per second in fast recording mode. This high-speed acquisition ensures that rare glitches and transient anomalies are captured with absolute fidelity.

To complement this speed, the series boasts an industry-leading 2 Gpts⁽¹⁾ memory depth, allowing users to record extensive periods of high-resolution data without sacrificing sample rates. Precision is further elevated by an adaptive 8 to 16-bit⁽²⁾ vertical resolution, which works in tandem with an exceptionally low noise floor and superior vertical accuracy. This powerful combination allows engineers to resolve micro-volt level signals with confidence, eliminating measurement uncertainty and delivering an exceptional, seamless test and measurement experience from the bench to the production line.

Notes:
1: 2 Gpts is an optional upgrade; the standard built-in memory depth is 500 Mpts. This 2 Gpts option is exclusively available for 4-channel models or the MSO model.
2: 16-bit resolution applies specifically to the Arbitrary Waveform Generator (AWG), which is an option available only on the MSO model.

Features

Based on RIGOL's brand new self-developed module
2/4 analog channels, 1 EXT channel
Max. 2 GHz / 2.5 GHz / 4 GHz / 6 GHz Analogue Bandwidth
Max. real-time sampling rate of 10/20 GSa/s
Max. memory depth of 2 Gpts⁴
Max. waveform capture rate of 1,000,000 wfms/s in fast recording mode
Vertical resolution: 8 to 16 bits⁵ selectable
Vertical sensitivity range: 1 mV/div to 10 V/div (1 MΩ), 1 mV/div to 1 V/div (50 Ω)
Time base range: 50 ps/div to 500 s/div
Up to 2,000,000 hardware real-time waveform continuously recording and playing function
Integrates various independent instruments into 1, including digital oscilloscope, function/arbitrary waveform generator¹, digital voltmeter, 8-digit frequency counter and totalizer, and protocol analyser (option)
Comprehensive trigger and bus decoding functions: Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Runt, Window, Delay, Setup/Hold, Nth edge, RS232, I2C, SPI, CAN, CAN-FD (option), FlexRay (option), LIN (option), I2S (option), MIL-STD-1553 (option), SENT Decode (option)
Search and navigation, mask testing, and zone trigger functions enable users to quickly identify abnormal signal events and locate them accurately
Auto measurements of 41 waveform parameters
Supports Ethernet, Automotive Ethernet, USB2.0, MIPI D-PHY, and other protocol compliance analysis functions (option)
Supports multiple functions, including digital signal analysis², Bode plot³, and histogram
Supports optional real-time eye diagram, jitter analysis, and power analysis
Multiple interfaces available: USB HOST & DEVICE, HDMI, AUX OUT, LAN(LXI), Web Control
10.1" 1280*800 HD touch screen display, portable design
User-friendly Flex Knobs for a smoother, more intuitive user experience

Applications

Electronic Design and Debugging: Prototyping, verifying, and troubleshooting complex analogue and digital circuits.
Embedded System Testing: Analysing and debugging microcontrollers, firmware, and integrated hardware systems.
Serial Bus Serial Decoding: Troubleshooting and validating communication protocols such as I2C, SPI, UART, CAN, and LIN.
Power Supply Analysis: Testing power integrity, switching losses, and efficiency in power supply unit (PSU) designs.
High-Frequency RF & Signal Integrity: Examining high-speed clock signals, identifying jitter, and performing eye diagram analysis.
Automotive Electronics: Testing and compliance checking for automotive networks, including Automotive Ethernet and CAN-FD.
Academic and Research Laboratories: Conducting advanced electronic experiments, sensor analysis, and engineering research.
Manufacturing Test and Quality Assurance: Automated testing on production lines to ensure product reliability and specification compliance.

Notes

1: Option available only on the MSO model.
2: Option available only on the MSO model.
3: Option available only on the MSO model.
4: 2 Gpts is an optional upgrade; the standard built-in memory depth is 500 Mpts. This 2 Gpts option is exclusively available for 4-channel models or the MSO model.
5: 16-bit resolution applies specifically to the Arbitrary Waveform Generator (AWG), which is an option available only on the MSO model.

Product Images

By replacing traditional mechanical attenuators with a <strong>Solid Electronic Attenuator</strong>, the DS/MSO9000 Series delivers improved lifetime and reliability in high-frequency, high-duty-cycle range switching applications.

More Reliable Range Switching

With up to <strong>2 Gpts memory depth</strong> and a waveform capture rate of up to <strong>1,000,000 wfms/s</strong>, the DS/MSO9000 Series helps engineers detect intermittent events faster and improve debugging efficiency.

Deep Memory, Zero Misses

Highly integrated and weighing only <strong>~5kg</strong>, the DS9000 Series is suitable for both efficient lab testing and portable field deployment.

Compact & Portable

Built-in tools such as <strong>eye diagram analysis, jitter decomposition, compliance testing, and power analysis</strong> enable users to move quickly from waveform observation to deeper insight.

Advanced Analysis in One

With up to <strong>6 GHz bandwidth</strong> and <strong>20 GSa/s real-time sampling rate</strong>, the DS/MSO9000 Series is built for high-speed signal capture, edge analysis, and complex anomaly detection.

6GHz Pure & Lossless

Product Videos

RIGOL MSO/DS9000 Series Digital Oscilloscope Overview

Standard Hardware Accessories

Rigol RP3500A 500MHz Passive Oscilloscope Probes, per channel
UK Power Cord

Optional Software Accessories

Optional Hardware Accessories

Documentation

Rigol MSO/DS9000 Datasheet

Rigol MSO/DS9000 Quick Guide

Model	DS9202	DS9204	DS9404	DS9604	MSO9402
Analogue Bandwidth (50 Ω, -3 dB)	2 GHz	2.5 GHz	4 GHz	6 GHz (half-channel^[2]) 4 GHz (all-channel^[3])	4 GHz
Analogue Bandwidth (1 MΩ, -3 dB)	500 MHz
Calculated Rise Time under 50 Ω^[1] (10%-90%)	≤210 ps	≤210 ps	≤110 ps	≤73 ps	≤110 ps
Number of Channels	DS9202: 2 analogue channels +1 EXT channel DS9204: 4 analogue channels +1 EXT channel DS9404: 4 analogue channels +1 EXT channel DS9604: 4 analogue channels +1 EXT channel MSO9402: 2 analogue channels +1 EXT channel +16 digital channels +2 function/arbitrary waveform generator output channels
Sampling Mode	Real-time sampling
Max. Sample Rate of Analogue Channels	10 GSa/s	half-channel^[2]: 20 GSa/s all-channel^[3]: 10 GSa/s
Max. Memory Depth	10 Mpts (all-channel^[3])	Standard: 500 Mpts (half-channel^[2]), 200 Mpts (all-channel^[3]) Option: 2 Gpts (half-channel^[2]), 1 Gpts (all-channel^[3])
Max. Waveform Capture Rate	1,000,000 wfms/s (in fast recording mode)
Vertical Resolution	8 bits (9-16 bits in high-resolution mode)

Notes:
1: The total rise time of the measuring system is calculated as:

Image of Screenshot 2026 05 20 131944
2: CH1 and CH2 are considered as a group; CH3 and CH4 are considered as another group. If one of the two channels in each group is enabled, it is called half-channel mode.
3: CH1 and CH2 are considered as a group; CH3 and CH4 are considered as another group. If two channels in either group are enabled, this is called all-channel mode.
