NoiseKen ESS-S3011A Electrostatic Discharge Simulator & GT-30R3302KB Discharge Gun – IEC 61000-4-2 ED 3.0 & ISO 10605 ED 3.0

Available on back-order

SKU: ESS-S3011A + GT-30R3302KB Categories: EMC, ESD Guns & Electrostatic Discharge Simulators Tag: General R&D Brand: NoiseKen

Description

The NoiseKen ESS-S3011A + GT-30R3302KB system is a versatile ESD immunity testing package compliant with both IEC 61000-4-2 Edition 3.0 and ISO 10605 Edition 3.0 standards.

It includes the ESS-S3011A main simulator and the GT-30R3302KB discharge gun, supplied with multiple CR units and discharge cups for immediate testing under both IEC and automotive ISO conditions.

This configuration supports a wide range of capacitance/resistance values (150 pF / 330 Ω – 330 pF / 2 kΩ), enabling accurate simulation of human-body and vehicle ESD events.

*Note, the Probe stand in the product image is a paid-for optional accessory.

Key Features

Complies with IEC 61000-4-2 Ed. 3.0 and ISO 10605 (3Rd Ed.) automotive and EMC test standards.
Multiple CR modules included for 150 pF / 330 Ω, 150 pF / 2 kΩ, 330 pF / 330 Ω, and 330 pF / 2 kΩ configurations.
Automatic CR & cup recognition for safe, accurate setup.
Discharge detection (air mode) and pre-check function ensure testing reliability.
Wide output range (0.2 kV – 30 kV) for component- to vehicle-level ESD evaluation.
Optical communication option for PC-based test control and logging.
LED-illuminated discharge gun tip for precise targeting of test points.
Supports both contact and air discharge methods.

Short Specifications

Output Voltage: 0.2 kV – 30 kV (± polarity)
Discharge Modes: Contact / Air
Available CR Configurations: 150 pF / 330 Ω, 150 pF / 2 kΩ, 330 pF / 330 Ω, 330 pF / 2 kΩ
Test Modes: IEC Standard / Manual / Sequence
Display: Color LCD touch interface on ESS-S3011A
Communication: Optical interface (optional)
Power Supply: AC 100–240 V, 50/60 Hz
Dimensions: Approx. 280 (W) × 125 (H) × 350 (D) mm
Weight: Approx. 6 kg (main unit)

What’s Included

ESS-S3011A simulator main unit
GT-30R3302KB discharge gun
CR units: 150 pF / 330 Ω (attached), 150 pF / 2 kΩ, 330 pF / 330 Ω, 330 pF / 2 kΩ
Discharge cups: 330 Ω (attached), 2 kΩ for ISO tests
Contact discharge tip (conical)
Air discharge tip (round)
High-voltage air discharge tip (spherical Ø 30 mm)
Gun holder, mounting hardware, and AC power cable
Instruction manuals

Compliance Standards

IEC 61000-4-2 Edition 3.0: ESD immunity testing for electronic and electrical devices.
ISO 10605 3rd Edition) Road vehicles – Test methods for electrical disturbances from electrostatic discharge.

Applications

Automotive electronics testing – ECUs, sensors, in-vehicle systems, and connectors per ISO 10605.
Consumer and industrial equipment – EMC compliance under IEC 61000-4-2.
R&D and validation – Flexible switching between standards for comparative testing.
Compliance laboratories – Certified and pre-compliance verification for both IEC and ISO requirements.

Product Images

Achieve a more reliable test

CR constant indicator

Discharge Detection Function

Infra-red Remote Controller

High visibility LCD Panel

Achieve a more reliable test

The new ESD simulator is equipped with 3 pre-check functions; “high voltage power output check”, “insulation failure check”, and “discharge relay operation check” on the main body and discharge gun. You can prevent troubles such as failing to perform the test properly; if you did not notice the failure of the tester body or the relay inside the discharge gun has reached the end of its life.

CR constant indicator

The constants of the discharge resistance and discharge capacitor, which were previously disassembled and checked, are now displayed on the main unit screen. When the CR unit or discharge cup of the discharge gun is replaced, it is automatically recognized and the type of CR unit is determined. The CR unit and the discharge cup are identified separately, and if the combination complies with the standard, the conforming standard is displayed at the bottom of the main menu.

Discharge Detection Function

It is possible to check the presence or absence of discharge during an air discharge test, which was difficult until now, by checking the buzzer sound from the tester and the LED display on the top of the discharge gun.

Infra-red Remote Controller

Since you can operate the tester with the remote control without returning to the tester during the test, the test can proceed smoothly.

High visibility LCD Panel

Reviewed the past operatability, adding Ten-key and Rotary knob realizing an easier and more comfortable operation. can be realized.

In “1 IEC STANDARD” in MAIN MENU, since the test levels are present, the test parameters can be set easily only with selection of the test level. In “2 MANUAL”, voltage, number of times interval and sweep settings of the test can be selected and also the set conditions can be saved. In “3 SEQUENCE”, the set conditions in MANUAL can be recalled for combining them so as to realize the arbitrary sequential tests. In addition, varied functions like setting for gun trigger, automated ESD eliminator, etc. are equipped.

Product Videos

Product Walkthrough

ESS-S3011A

ESD Voltage Meter MODEL : 18-00086B

Using an ESD gun for troubleshooting immunities - Dr Min Zhang- Mach One Design EMC

Standard Hardware Accessories

Optional Hardware Accessories

Documentation

Catalogues

ESD Simulator_S3011A

ESD Simulator_PS1

Repair Status and Successor Equipment

User Manuals

ESS-S3011A Aaronia BPSG Datasheet

GT-30RA/GT-30R3302KA Aaronia BPSG Datasheet

ESS-PS1 & GT-31S

Parameter	Specification
Polarity	Positive / Negative
Output voltage	0.20 kV ~ 30.0 kV(30.5 kV max) *0.20kV ~ 1.99kV ±10% 2.00kV ~ 30.0kV ±5% ~ 10.0 kV : 0.01 kV step ~ 30.0 kV : 0.1 kV step
Repetition cycle	0.05s ~ 600s ±10% / Manual Set step : 0.01s (0.05 ~ 9.99s), 0.10s (10.0 ~ 600.0s)
Discharge number of times	1 ~ 60,000 times, Preset 1 time step or continuous preset
Discharge mode	Contact discharge / Air discharge
Radiation level mode	NORMAL mode / EXTRA mode
Trigger mode	Gun trigger / Main trigger / External trigger
Operation panel	Colour LCD / Push-buttons (Partially lighting)
Gun holder	Standard attached (to hold the discharge gun Model GT-30RA)
Radiation mode select switch	Extra / Normal switching function built-in
Discharge detection	Discharge detection function in air-discharge-equipped
Pre-checking function	Following 3 steps function equipped (by user operation. Not the calibration, but just checking) STEP 1: High voltage output checking STEP 2: Withstanding voltage checking STEP 3: Discharge relay operation checking
CR & Gun head checking	CR constant and gun head recognisable (indication to prevent a wrong combination)
“IEC STANDARD” test mode	Contact discharge mode: 2.0 kV, 4.0 kV, 6.0 kV and 8.0 kV steps Air discharge mode: 2.0 kV, 4.0 kV, 8.0 kV and 15.0 kV steps
“MANUAL” test mode	Contact / Air discharge mode, Arbitrary setting 0.2 kV ~ 30.0 kV Sweeping function built-in, Recordable up to 99 units
“SEQUENCE” test mode	Enables continuous operation of units set to MANUAL mode. Max. 22 steps / 1 program, and the programs are recordable up to 20.
Warning lamp	Lighting at the voltage output from the generator. Blinking at electrostatic discharging.
Charge capacitor/resistor	150 pF±10%, 330Ω±10% (Built-in CR unit for discharge gun GT-30RA)
Charge the resistor in the generator	10 MΩ (Totally 53Ω in combination with 43 MΩ in discharge gun) *
AUX connector	D-SUB 15-pin female connector (for connecting to Patolight, automated ESD eliminator, external interlock input, external trigger input terminal)
Optical communication	Optical connector (serial interface) for connecting to a PC connector
Power supply/consumption	AC100 V ~ AC240 V 50 Hz / 60 Hz ±10% 75VA
Dimensions	Generator : (W)392 mm × (H)312 mm × (D)295.3 mm (gun holder included) Discharge gun : (W)83.3 mm × (H)217.2 mm × (D)229.3 mm
Weight	Generator: approx. 7.5 kg (with Gun Holder) Discharge gun: approx. 1080 g (cable and connector excluded)
