Brymen BM789 Professional Multimeter

£112.00 (£134.40 inc VAT)

10+ In UK Stock

Availability: Stock models delivered next working day (UK only) for orders placed before 15:00 (Mon - Fri)

Free Shipping Price Match Guarantee
SKU: BM789 Categories: ,

Description

Brymen BM789 Professional Multimeter

Brymen BM789 Professional Multimeter 60,000 Counts, 100kHz TRMS and CAT-III 1kV Now Over-molded Ergonomic, AutoHold Real-Read, BeepLit Continuity, BeepLit Diode Alert, Hi-Lo EF Detection, VFD V & Hz, Crest Peaks, Speedy MaxMinAvg, Relative Zero and BeepJack.

Telonic Offer: Supplied with Silicone Test Leads with gold-plated tips with screw-on banana plugs (BL21S2-T4SC).

Features:

  • ACV Bandwidth up to 100kHz
  • dBm Readings with selectable Reference Impedance Values
  • AutoV LoZ Ghost-Voltage-Buster Feature; Automatic Selection of ACV and DCV
  • T1-T2 Dual Input Type-K Temperature -200.0°C to 1090°C; Selectable °F Readings
  • %4~20mA Readings to test process control loop currents
  • nS Range 99.99nS to Extend Resistance Measurements
  • 4-5/6 Digits 60,000 Counts max large easy-to-read LCD display
  • Nominal 5/sec fast measurements; Fully auto-ranging
  • 31 Segment Analogue bar-graph updates 50/sec
  • Best basic DCV Accuracy up to 0.03%+2d
  • Warm white back-lighted LCD display
  • DC+AC, AC True RMS Conversion
  • Intelligent Auto Power Off
  • Data Hold
  • Relative Zero Mode
  • Crest (peak hold) captures MaxMin Changes > 0.25ms in durations
  • Autohold Real-Read Shows real-time readings to avoid blind measurements
  • Speedy record MaxMinAvg Readings; Updates 10/Sec Nominal on DC Measurements
  • VFD-V & VFD-Hz Measures Fundamental V & Hz of most variable frequency drives
  • DC, AC, DC+AC Voltage Ranges 600.00mV to 1000.0V
  • DC, AC, DC+AC uA, mA & A Ranges 600.00uA to 10.000A
  • Ohms Ranges 600.00Ω to 60.000MΩ
  • Capacitance Ranges 10.00nF to 10.00mF
  • Line Frequency Ranges 99.999Hz to 50.000kHz
  • Logic Frequency Ranges 99.999Hz to 1.0000MHz
  • BeepLit Continuity Tester. Features Audible Beep & Visible Backlight Effects
  • BeepLit Diode Tester. Short-Beep Alert and Voltage threshold continuity
  • BeepJack Input warning against improper plug into uAmA/A terminals
  • Rugged fire retarded casing with battery compartment cartridge
  • Over-molded protective holster with probe-holders and tilt-stand
  • Optional purchase magnetic hanger strap
  • HBC 1kV Fuses protected on uAmA/A Terminals
  • Transient Protection up to 8kV 1.2/50us Lightning Surge
  • LVD meets EN61010-1/-2-030/-2-033 to measurement CAT III 1000V & CAT IV 600V
  • EMC meets EN61326-1

Brymen Handheld Multimeter Comparison Table

Model Digits Counts DC Voltage / Current Range AC Voltage / Current Range OHMS Ranges Line Level Frequency Range
BM235 3-5/6 Digits 6,000 Counts 600.0mV - 1000V 600.0mV - 1000V 600.0Ω - 60.00MΩ 99.99Hz - 50.00kHz
BM257s 3-5/6 Digits  6,000 Counts 0.01mV - 1000V 0.01mV - 1000V 0.1Ω - 60MΩ 10.00Hz - 10.00kHz
BM785 4-5/6 Digits 60,000 Counts 600.0mV - 1000V 600.0mV - 1000V 600.00Ω - 60.000MΩ 99.999Hz - 50.000kHz
BM789 4-5/6 Digits 60,000 Counts 600.0mV - 1000V 600.0mV - 1000V 600.00Ω - 60.000MΩ  99.999Hz - 50.000kHz
BM867s 5-4/5 Digits 500,000 Counts 0.001mV - 1000V 0.01mV - 1000V 0.01Ω - 50MΩ 10Hz - 200kHz
BM869s 5-4/5 Digits 500,000 Counts 0.001mV - 1000V 0.01mV - 1000V 0.01Ω - 50MΩ 10Hz - 200kHz
BM877 3-5/6 Digits  6,000 Counts 60.00mV - 1000V 60.00mV - 1000V 600.0Ω - 60.00MΩ ---
BM878 3-5/6 Digits  6,000 Counts 60.00mV - 1000V 60.00mV - 1000V 600.0Ω - 60.00MΩ ---
BM887 3-5/6 Digits  6,000 Counts 60.00mV - 1000V 60.00mV - 1000V 60.00Ω - 60.00MΩ 9.999Hz - 100.0kHz

Documentation

General Specifications
Manufacturer Brymen
Display 60000, Backlighted, Bargraph
Sampling 5 x/s
True RMS AC, AC + DC
Accuracy (DCV) 0.03% + 2d
Function & Features Professional Multimeter
Other Measurements (Max Range) Capacitance 10mF, AC/DC Current, Conductance 99nS, Continuity, Frequency (logic), Frequency 1MHz, Resistance, Temperature T1,T2
Special Features Auto-Hold Real Read™, BeepLit™Continuity, BeepLit™Diode, Intelligent AutoPower-Off, 4~20mA, AutoV LoZ, Beep-Jack™, dBm, DUTY%, VFD (ACV+Hz)
Special Functions Crest 35ms, AVG, HOLD, MAX, MIN, REC, REL
Overload Protection 1000V
Surge Protection 8kV
Measurement Category (Safety) CAT III
Category Voltage 1000V
Standard Accessories Silicone test leads BL21S2-T4SC, Battery installed, BKP60 K-type thermocouple, User’s manual
Optional Accessories BMH-02 Magnetic hanger
Dimensions 89mm X 51mm X 193mm
Weight 635g

Note*

Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
