The DP832 is a triple output power supply. CH1 and CH2 are +30V supplies, and CH3 is a 5V supply.
To configure the instrument as a +/-30V or lower, you can use the instrument ground plug located on the front panel:
![](https://rigol--c.na47.content.force.com/sfc/dist/version/download/?oid=00DA0000000IWhw&ids=0684A000005Xf8W&d=%2Fa%2F4A000000UB7d%2FfMw2vurSansJGPp17160wmFX9QG0gpW7b8y9UvOvyU8&asPdf=false)
– Select which channel you want to be + and which you want to be – (in this note, we will select CH1 as -, CH2 as +)
NOTE: The jumper wires connected to the DP832 ground must use wire rated for 9A or greater to prevent damage or a possible fire hazard.
– Connect the power supply up as follows (we are including CH3 here)
![](https://rigol--c.na47.content.force.com/sfc/dist/version/download/?oid=00DA0000000IWhw&ids=0684A000005Xf8V&d=%2Fa%2F4A000000UB7e%2F5TY8WIEbq5pN0LRL5gEwLj4nCn9ypYWZ2mf1UjLb89k&asPdf=false)
– Configure the channels for the proper voltage, current, and limits that they require.
NOTE: CH1 true polarity will be negative (-) with respect to the DP832 Ground Connection, even though the programmed voltage will indicate positive (+)
– Enable the power supply outputs by pressing the ON/Off buttons for each channel
– To make operation easier, you can also activate Tracking between Channel 1
and Channel two by pressing Utility > System > Track Set > Set Track to
“Synchronous”. This will allow you to adjust the output value for Channel 1
and Channel 2 will follow.
For floating connections (without earth ground)
– Select which channel you want to be + and which you want to be
– (in this note, we will select CH1 as -, CH2 as +)
Connect the power supply up as follows (we are including CH3 here)
![](https://rigol--c.na47.content.force.com/sfc/dist/version/download/?oid=00DA0000000IWhw&ids=0684A000005Xf8U&d=%2Fa%2F4A000000UB7f%2FE1pLOU8HJ_RSxK8NYSr1z9w148UHdE.XoIhm2GXD8jE&asPdf=false)
![](https://rigol--c.na47.content.force.com/sfc/dist/version/download/?oid=00DA0000000IWhw&ids=0684A000005Xf8T&d=%2Fa%2F4A000000UB7g%2FxvSBQ55epwDlPIVxOEyah5jPbX0Dyc004MuiWweXq4Q&asPdf=false)
NOTE: The jumper wires connecting CH1 +, CH2 –, and CH3 – must use wire rated for 9A or greater to prevent damage or a possible fire hazard.
Configure the channels for the proper voltage, current, and limits that they require.
NOTE: CH1 true polarity will be negative (-) with respect to the DP832 Ground Connection, even though the programmed voltage will indicate positive (+)
– Enable the power supply outputs by pressing the ON/Off buttons for each channel
– To make operation easier, you can also activate Tracking between Channel 1 and Channel two by pressing Utility > System > Track Set > Set Track to “Synchronous”. This will allow you to adjust the output value for Channel 1 and Channel 2 will follow.
