TEKBOX TBCS101-DA Differential Amplifier

General specification

• Frequency range: DC – 310 MHz, 3 dB bandwidth, typical
• Gain: 1:50
• Rise time: ≤ 2.3 ns ( 200mV step)
• RF-connectors: BNC-female

Input specification

• Input impedance: 1 MΩ // 10pF
• Maximum input level: max. ± 50 V for linear operation (100V differential mode)
• Maximum ratings: max. ± 100 V common mode / 200 V differential mode for damage

Output specification

• Output impedance: 50 Ω
• Output return loss: > 20 dB, typ.
• Common Mode Rejection: DC – 1 MHz > 70 dB; 1 MHz – 100 MHz ≥ 80 dB; 100 MHz – 310 MHz ≥ 50 dB
• Max. output voltage: 2 Vpp
• DC offset: < 10mV at output
• Noise: < 1.4 mVRMS

Supply specification

• Power-connector: USB-C
• Indicator LEDs: Power ON
• Operating voltage: 5 V DC
• Current consumption: 90 mA
• Operating temperature range: -20°C to +50°C
• Dimensions: W 82 mm x H 33 mm x L 80 mm
• Weight: 100 g
