Description
This product is a Current Probe that can be used with Siglent Oscilloscopes.
See the “Specification” Tab for more information.
| Model | SCP5030 (A) | SCP5150 | SCP5500 | ||||
|---|---|---|---|---|---|---|---|
| Bandwidth (-3 dB) |
SCP5030 | DC-50 MHz | DC-12 MHz | DC-2 MHz | |||
| SCP5030A | DC-100 MHz | ||||||
| Rise Time | SCP5030 | ≤ 7 ns | ≤29 ns | ≤175 ns | |||
| SCP5030A | ≤ 3.5 ns | ||||||
| Continuous maximum input range | SCP5030 | 30 Arms | 150 Arms | 500 Arms | |||
| SCP5030A | 30 Arms | ||||||
| Max peak current value | 50 Apk | 300 Apk | 750 Apk | ||||
| Range | 5 A | 1X | 30 A | 10X | 75 A | 10X | |
| 30 A | 10X | 150 A | 100X | 500 A | 100X | ||
| Overload | 5 A | ≥5 A | 30 A | ≥30 A | 75 A | ≥75 A | |
| 30 A | ≥50 A | 150 A | ≥300 A | 500 A | ≥750 A | ||
| Current transfer ratio | 5 A | 1 V/A | 30 A | 0.1 V/A | 75 A | 0.1 V/A | |
| 30 A | 0.1 V/A | 150 A | 0.01 V/A | 500 A | 0.01 V/A | ||
| Resolution | 5 A | 1 mA | 30 A | 10 mA | 75 A | 10 mA | |
| 30 A | 10 mA | 150 A | 100 mA | 500 A | 100 mA | ||
| Accuracy (DC, 45-66 Hz) |
5 A | ±1%±1 mA | 30 A | ±1%±10 mA | 75 A | ±1%±10 mA | |
| 30 A | ±1%±10 mA | 150 A | ±1%±100 mA | 500 A | ±1%±100 mA | ||
| Input resistance | SCP5030 |  |
 |
 |
|||
| SCP5030A |  |
||||||
| Delay | Probe | 14 ns | 36 ns | 42 ns | |||
| BUS cable (1 .5m) |
7.5 ns | ||||||
| Terminal load requirements | ≥100 kΩ | ||||||
| Power Supply | Directly powered by the oscilloscope through SAPBUS | ||||||
| Voltage of insulated wire | 300 V CAT I | 600 V CATII 300 V CATIII | |||||
| Terminal load requirements | EN61010-1: 2010+A1:2019 EN 61010-2-032:2019 | ||||||
| Terminal load requirements | EN61326-1:2013 EN61000-3-2:2014 EN61000-3-3:2013 | ||||||
