Siglent SAG1021I External Arbitrary Waveform Generator

Siglent SAG1021I External Arbitrary Waveform Generator

£202.00 (£242.40 inc VAT)

1 in stock (can be backordered)

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

Request QuoteRemove from Quote
Request Quote
SKU: SAG1021I Categories: , , , Brand:

Description


Siglent SAG1021I External Arbitrary Waveform Generator

Accessory for use with the four-channel SDS1000X-E scopes and all of the SDS800X HD, SDS1000X HD, SDS3000X HD, SDS5000X or SDS6000A scopes.

Output Sine, Square, Ramp, Pulse, Noise, DC and 45 built-in waveforms. The arbitrary waveforms can be accessed and edited by the EasyWave PC software.

In order to activate the MSO functionality a corresponding option license xxxx-FG is required which is included with the latest revision of the firmware

Latest Firmware can be downloaded “here”

Outputs: 1
Max. Output Frequency: 25 MHz
Sampling Rate: 125 MSa/s
Frequency Resolution: 1 μHz
Frequency Accuracy: ±50 ppm
Vertical Resolution: 14-bit
Amplitude Range: 1.5 ～ +1.5 V (50Ω load), -3 ～ +3 V (High-Z load)
Waveform Types: Sine, Square, Ramp, Pulse, Noise, DC and 45 built-in waveforms
Output impedance: 50 Ω±2%
Protection: Over-Voltage Protection, Current-Limiting Protection
Insulation Voltage: ±42 Vpk
